Product Center

Goods Details




PARAMETER
DETAILS
Light source
SMD 2835
Working temps
-20℃~40℃
Beam angle
120°
Color Temperature(CCT)
2700K /3000K /4000K/6500K
CRI (Ra>)
80/90/95
Input Voltage
AC100-240V 50/60Hz
Lamp Luminous Efficiency(lm/w)
90-130lm/w
Material
Die cast aluminum
IP rating
ip20
Safety Class
II
Option
Dimmable
Warranty
3 Years
Applications
hotel&indoor

High luminous efficacy , Enery savings up 80% ,

Easy installations with fast connection


GUANGDONG QIKE ELECTRONICS CO.,LTD

Wechat Scan QR Code to sign in

Copyright © GUANGDONG QIKE ELECTRONICS CO.,LTD  技术支持：江门华企立方科技有限公司  粤ICP备20025704号
Model
LED
LED QTY
CRI (Ra>)
Driver
PF
lumen
D*H
(mm)
Cut-out (mm)
QK-DL-CMD-7W
SMD
2835
14
80
AC100-240v
AC160-240v
0.5/0.9
90-110lm/w
Φ100*30
Φ80
QK-DL-CMD-10W
SMD
2835
21
80
AC100-240v
AC160-240V
0.5/0.9
90-110lm/w
Φ120*33
Φ100
QK-DL-CMD-15W
SMD
2835
